Model NO.:
HDV-01
Delivery:
FOB
Supply Ability:
500 / Day
Country of Origin:
SHENZHEN
Stock Time:
5 Days

Overview

HD Video to fiber converters adopt the advanced uncompressed HD composite video and high velocity digital optical transmission technologies which convert the HD video composite signals to optical signals to achieve long distance(as far as 80Km) transmission through fibers.

Features

  • Non-compression coding technology
  • Automatically identify formats of input videos.
  • Support transmission of 1 channel HD video signal and controlling data simultaneously though coaxial cable
  • DC 5V power supply
  • Support 720p/25,720p/30,720p/50,720p/60,1080p/25,1080p/30 videos etc.
  • Through LED indicators to inform its functional mode
  • Industrial wide range of operational temperature
  • Plug and play, simple installation.

Application

  • Intelligence Traffic Monitor system(ITS)
  • Metro/High-speed way monitor system
  • Electric power/hydraulic Safety Monitor system
  • Industrial mining enterprises Security System
  • Long-distance multimedia teaching/ Campus Security
  • CATV long-distance transmission
  • Building Automatic Security System

Technical Indexes

Parameter

Specifications

HD Video

Interface

BNC

Input level

>500mVp-p

Output level

1Vp-p

Input/Output Impedance

75 Ω

Bandwidth

30MHz(720P); 60MHz(1080P)

Digit bit width

8bit

Data

Interface

Standard industrial terminals

Interface Signals

RS485

Baud Rate

1200~9600bit/s

Bit Error Rate

<10-9

Optical

Interface

FC (default) ,SC,ST (optional)

Fiber Type

Single mode, single fiber (default)

Distance

0km~80km

Wavelength

1310nm/1550nm

General

Indicators

LOS,PWR,VIDEO

Mean time between failures(MTBF)

>100 000 hours

Power supply

DC5V/1A

Operating Temperature

-20 C~+70 C

Humidity

0%~95% (non-condensing)

Dimension

720P Device:10.4*10.4*2.8mm,0.25kg;

720P Packing: 25*14*7.5mm,0.75kg;

1080P Device:10.4*10.4*2.8mm,0.25kg;

1080P Packing: 25*14*7.5mm,0.75kg

Order Information

Model No.

Description

HDV-0107DT

720P; 1-ch HD Video to Fiber; FC 20km; Transmitter

HDV-0107DR

720P; 1-ch HD Video to Fiber; FC 20km; Receiver

HDV-0117DT

720P; 1-ch HD Video + 1-ch return data to Fiber; FC 20km; Transmitter

HDV-0117DR

720P; 1-ch HD Video + 1-ch return data to Fiber; FC 20km; Receiver

HDV-0108DT

1080P; 1-ch HD Video to Fiber; FC 20km; Transmitter

HDV-0108DR

1080P; 1-ch HD Video to Fiber; FC 20km; Receiver

HDV-0118DT

1080P; 1-ch HD Video + 1-ch return data to Fiber; FC 20km; Transmitter

HDV-0118DR

1080P; 1-ch HD Video + 1-ch return data to Fiber; FC 20km; Receiver
