IMS3210-204 Industrial Managed Switch are fully managed L2 switches, adopt store-forward architecture, fan-less and energy-saving design, with 4*10/100/1000Base-T port and 2*1.25G/155M SFP fiber port. Full-series design with protection against lightning,anti-static and operate in -40°C~85°C for harsh environments; such as industrial automation, public security, power system, intelligent transportation systems (ITS),shipping, mining ,water conservancyand oil fields.
HardwareFeatures
ERPS (G.8032)
Loop Protection
Redundant dual DC input power 12/24/48VDC (9.6~60VDC)
Provide power polarity reverse,Overload current protect function
2.25K VDC Hi-pot isolation protection for Ethernet ports and power
4KV surge protection for UTP and fiber ports
SFP 100/1000Base-X
IP40 Aluminum metal case protection
DIN-rail default, Wall Mount kits optional
Supports EFT protection 6000VDC for power line
Supports 8~15KV ESD protection
-40°C~85°C operating temperature
Low power consumption
Technical Specifications
Standards
IEEE802.3 10BASE-T; IEEE802.3u 100Base-TX
IEEE802.3ab 1000Base-T; IEEE802.3z 1000Base-X
IEEE802.3xFlow control and back pressure; IEEE802.1Q VLAN
IEEE802.1w RSTP
IEEE802.1s MSTP
IEEE802.1d STP
Switching Capacity
12Gbps/non-blocking
MAC Address Table
8K
Data Buffer
4M
Maximum Frame Size
9.6K Jumbo Frame
Copper
4*10/100/1000Base-T, RJ45
ESD protection
EFT protection
Fiber
2*100/1000Base-X,SFP Slot
Console
RS232 (RJ45)
Key Switch
Reset
Power
DC:12V~58V,
6-PIN Removable Terminal Block
Overload voltage protection
Overload current protection
Reverse Polarity protection
Lightning protection:6KV
ESD: 8~15KV
LED Indicators
PWR, RUN, Link/Act, Speed, Fiber Link
Operating Temperature
-40 ˚C~+85 ˚C
RelativeHumidity
5-95% (no condensation)
Housing
IP40 Protection, Aluminum Alloy, fan-less
Mounting
DIN-rail 35-7.5, wall mounting(with optional kit)
Dimensions
138*107*45mm(device); 215*175*73mm(packing)
Weight
0.52kg(device); 0.65kg(device with packing)
Regulations
CE/FCC/ROSH
Software Feature
L2 Features
Port Features
IEEE 802.3x flow control
Interface counters
Storm control
Port isloated
Link Aggregation
Static aggregation
Dynamic aggregation, LACP
Mirror
Port-based mirror
Vlan-Based
Flow-Based
Spanning Tree
IEEE802.1d STP
IEEE802.1w RSTP
IEEE802.1s MSTP
VLAN
Port-based VLAN
access/trunk/hybrid-port
4094 IEEE802.1Q VLAN VID
GVRP
Mac-address table
IEEE 802.1q
MAC address: 8K
Support MAC address automatic learning and aging
Static mac-address
Dynamic mac-address
Security mac-address
Loop Protection
Supported
Private VLAN
Supported
ERPS (G.8032)
Single ring
Sub-Ring
Multi-ring
Load balance
Recovery Time < 50ms
Layer 2 Multicast
IGMP Snooping V1/V2/V3
Source Port Check
IGMP Fast Leave; Filter, Agent
Security
ACL
ACL (IP Standard ACL), IPV4/IPV6
MAC extend ACL;IP extend ACL
Support matching L2, L3, L4 layer fields
Support log, redirection, mirroring, speed limit
QoS
QoS Class, Remarking
SP, WRR queue scheduling
SP,WRR, SP+WRR
Ingress Port-based Rate-limit
Ingress Priority-based Rate-limit
Egress Port-based Rate-limit
Egress Queue-based Rate-limit
Policy-based QoS
Storm Control
IEEE 802.1p 8 active priorities queues for per port
Dot1x
Port Access Control
User Access Control
Mac-address Access Control
RADIUS Server
IP Source Guard
Support dynamic table entries
Support static table entries
ARP Inspection
Support dynamic table entries
Support static table entries
Port Security
Supported
Access Management
Supported
Management
User management
Password protection
SNMP
SNMP V1/v2C/V3
RMON
Statistics Group
History Group
Alarm Group
Events Group
CLI
Support
RADIUS client
Support
Web management
HTTP V1.1, HTTPS
Firmware Upgrade
Reversion Upgrade
Syslog/Debug
Support
IPV4/IPV6
Support
Diagnosis
ping(ipv4)
ping(ipv6)
Trace route(ipv4)
Trace route(ipv6)
Application
NTP
NTP Client
DHCP
DHCP Client
DHCP Snooping
Trust Port
Telnet
Telnet Server
TFTP
TFTP Client
SSH
SSH Server
Order Information
Model No.
Description
IMS3210-204
4*10/100/1000Base-T + 2*100/1000Base-X, SFP slot
Note:
Power supply provided by user or ordered additionally
